In every compressed air system, piping is a crucial component. You will have to ensure that the pipes connect in the right way and you also have to choose the right tubes to avoid poor transmission of air. When you look at some of the best systems, you will notice that they have many features in common.

For instance, these pipes ensure that the pressure of air is sufficient for the purpose it is meant to achieve. That’s just one of the reasons you need to take time to identify the right compressed air piping design before using it. Although there are many considerations to make before choosing the right product, here are selected few that play a significant role in the functionality of such systems.

Check the materials

When you want to control the pressure of controlled air, you have to check the pipe materials. This is also an important step to perform when monitoring quality. You will notice that some materials are only useful at certain pressure levels; in this case, exceeding their limit will make the system useless. However, there are materials that can withstand a wide range of pressure and quality levels depending on what function you require from an air compressor. Air compressor pipes should help you to achieve the best quality.

Know the size and distance

When talking about the size of air compressor pipes, you should think about the diameter. Scientific research shows that pressure varies depending on the wideness of pipes. To keep the pressure constant, you will have to come up with a compressed air piping design that introduces checks and controls at every point. You will also notice that apart from the size, the distance from beginning to end determines the pressure levels. For instance, the compressor may exert a lot of pressure, but it will be lost when the point of use is too far. Most compressed air distribution systems create the point of use at the closest possible distance for the best pressure control.

Know the piping layout

The main layouts in a compressed air piping design are straight and loop. A loop layout focuses on delivering air to each point of use through wide pipes. It is preferred for square plants because of this delivery method. On the other hand, you will choose a straight layout if you are working with plants that are narrower and longer. This layout often has branches so that you can maintain the right temperature levels. In order to choose the best compressed air piping design, you need to understand the plan that is best suited for your work.

Check the temperatures

At what temperatures will the compressed air piping systems be working? Sometimes, you will need a different compressed air piping design for different temperature levels. This is because different temperatures affect the quality and quantity of air in the pipes. Compressed air systems for heavy equipment are relatively large, and so, they may not be affected by temperature fluctuations. However, you have to be on the lookout for any changes in smaller applications since the temperature can adversely affect your compressed air.

Inquire about the maintenance needs

Compressed air piping materials come in different forms, and they need different maintenance practices. You will notice that some need a lot of care, but others may not be too fragile. Therefore, you should know how often you will be calling a technician to inspect them. When they do this, they help you to keep the compressors in the best shape. It is also important when it comes to the durability of these compressors; after all, you don’t want to keep buying or repairing them.

Are you interested in compressed air piping designs for your business? Rely on Rapid Air Products for more information today.
