MaxLine

INDUSTRIAL-GRADE SEMI-FLEXIBLE TUBING

MaxLine’s patented semi-flexible tubing maintains its shape after bending, using compression fittings for efficient, leak-proof delivery of clean compressed air. With a HDPE inner/outer layer and a smooth aluminum center, MaxLine remains corrosion free for decades, can be buried underground and can be installed in half the time of traditional methods.

Get versatile, leak-proof performance with MaxLine.

SIZING

1/2” MAXLINE

Outside Diameter: 16 mm (.63 in)

1” MAXLINE

Outside Diameter: 32 mm (1.26 in)

3/4” MAXLINE

Outside Diameter: 25 mm (.98 in)

2” MAXLINE

Outside Diameter: 63.5 mm (2.5 in)

MaxLine
MaxLine

COMMON APPLICATIONS

SYSTEM PRESSURE RATINGS

COMPRESSED AIR

200 psi

COMPRESSED AIR

190 psi

INERT GAS

200 psi

INERT GAS

190 psi

VACUUM

Up to 29” hg

VACUUM

Up to 29” hg

PIPE/TUBING

MATERIAL

Multi-Layer Industrial-Grade Tubing: HDPE + Aluminum

MATERIAL

Aluminum Alloy

FORM

Rigid, semi-flexible compressed air tubing maintains shape after bending

FORM

Rigid aluminum piping for long, straight piping runs

FEATURES

BENDABILITY

Ideal for layouts with obstructions

Tubing can sweep/bend corners without elbow fittings

BENDABILITY

Ideal for straight piping runs

Elbow fittings needed for corners

INSTALLATION OPTIONS

Can be buried underground or in concrete

INSTALLATION OPTIONS

Can be installed on wall or hanging from ceiling

FLUID SPECIFICATIONS

Designed to be used with compressed air and inert gases

FLUID SPECIFICATIONS

Designed to be used with compressed air and inert gases

MaxLine

COMMON APPLICATIONS

SYSTEM PRESSURE RATINGS

COMPRESSED AIR

190 psi

INERT GAS

190 psi

VACUUM

Up to 29” hg

PIPE/TUBING

MATERIAL

190 psi

FORM

Rigid aluminum piping for long, straight piping runs

FEATURES

BENDABILITY

Ideal for straight piping runs

Elbow fittings needed for corners

INSTALLATION OPTIONS

Can be installed on wall or hanging from ceiling

FLUID SPECIFICATIONS

Designed to be used with compressed air and inert gases

CAN BE BURIED UNDERGROUND OR IN CONCRETE.
MaxLine holds any bent shape.

EASY INSTALLATION, BUILT TO LAST

MaxLine’s semi-flexible tubing comes in 100 or 300 ft coils (special orders for longer lengths), using compression fittings for leak proof performance that delivers clean compressed air. Perfect for “rugged” sites with obstructions and corners, MaxLine can be buried underground and can be installed in half the time of traditional methods.

MaxLine’s smooth aluminum inner surface delivers air efficiently and remains corrosion free for decades.

SHOP

MASTER KITS

Versatile and easy to install in small shops to large manufacturing facilities, MaxLine can be applied on wall, in wall or underground. MaxLine’s HDPE tubing and nickel plated fittings prevent corrosion to ensure clean, efficient air flow.

MaxLine connects to any existing piping system to easily expand or modify system layout.

SHOP

FITTINGS

COMPRESSION

Reusable compression fittings are ideal for residential or commercial spaces that need the flexibility to expand/modify their compressed air system.

THE

COMPRESSION

ADVANTAGE

No press tool is required for install; fittings can be disassembled and reused.

Compression fittings are suitable for air, vacuums and inert gases.

Fittings are made with fiberglass reinforced nylon (2” fittings and under) or black aluminum die cast (3” fittings).

PRESS

Easy to install and built to last without maintenance, permanent press fittings are ideal for bigger industrial/commercial spaces that will not change compressed air systems frequently.

THE

PRESS

ADVANTAGE

Press tools create easy, permanent, and reliable connections.

When used with MaxLine, press is suitable for compressed air, vacuum and inert gas.

The stainless steel material provides long-term UV sensitivity and remains leak free without readjustments once the fitting is pressed on.

SHOP

TOOLS & ACCESSORIES

As your single source for complete industrial grade compressed air solutions, RapidAir has everything you need to streamline operations.
