System | Compressed Air: 190 psi max Inert Gas: 190 psi max Vacuum: up to 29 in hg | | Compressed Air: 200 psi max Inert Gas: 200 psi max Vacuum: up to 29 in hg | | Compressed Air: 200 psi max Inert Gas: 200 psi max Vacuum: up to 29 in hg NSF, FDA, CSA rated | | Compressed Air: 150 psi max |
---|
Pipe/Tubing | Rigid, Straight Aluminum alloy pipe | | Multi Layer Tubing HDPE-Aluminum-HDPE Maintains shape after bending | | Multi Layer Tubing PERT-Aluminum PERT Maintains shape after bending | | Single Layer Tubing Nylon material |
---|
AVAILABLE SIZES | 3/4″, 1″, 1 ½” , 2″, 3″, 4″, 6″ O. D. Pipe lengths 19 ft 8 in, and 7 ft 6 in | | 1/2″, 3/4″, 1″, 2″ 1/2″ thru 1″: 25 ft, 50 ft, 100 ft, 300 ft 2″: 100 ft and 200 ft rolls | | 1/2″, 3/4″, 1″ 100 ft and 300 ft rolls | | 1/2” O.D x 3/8″ I.D 100 ft rolls |
---|
Fittings | | 3/4″ thru 2″ Compression Style Fiberglass / Nylon | | 3″ thru 6″ Aluminum die Stamped steel |
| | | 1/2″ thru 1″ Compression Style Nickel Plated Brass Stainless Steel option | | 2″ Crimp style Nickel Plated Brass Stainless Crimp Ring |
| | | 1/2″ thru 1″ Compression Style Nickel Plated Brass |
| | | Push to Connect Style Nickel Plated Brass Nylon |
|
---|
Application | - Straight piping runs
- Elbow fittings needed for corners
- Professional look needed
- Multiple air users
- On wall / hanging installation
| | - Layouts with many obstructions
- Tubing can sweep/bend corners
- Long continuous piping lengths
- Direct burial
- In wall/on wall installations
- Economical
| | - Layouts with many obstructions
- Tubing can sweep/bend elbows
- Long continuous piping lengths
- Direct burial
- In wall/on wall installations
- Food/Beverage applications
- Oxygen Service
| | - Home garage / workshop
- Hobbyist woodworking
- In wall / on wall installation
- Single air users
|
---|
GENERAL SIZING GUIDE | Distance from the air compressor to the farthest outlet point up to 150 ft use 3/4″ FastPipe up to 300 ft use 1″ Fastpipe
| | Distance from the compressor to the farthest outlet point up to 75 ft use 1/2″ MaxLine up to 200 ft use 3/4″ MaxLine up to 300 ft use 1″ MaxLine
| | Distance from the air compressor to the farthest outlet point up to 75 ft use 1/2″ Duratec up to 200 ft use 3/4″ Duratec up to 300 ft use 1″ Duratec
| | Distance from the air compressor to the farthest outlet point up to 50 ft For building sizes under 1200 sq.ft
|
---|
